95ton Used Zoomlion Truck Crane Zoomlion ZTC950V Second Hand Truck Mobile Crane

Name: 95ton Used Zoomlion Truck Crane Zoomlion ZTC950V Second Hand Truck Mobile Crane
Brand: Zoomlion
Price: 1 USD

China 95ton Used Zoomlion Truck Crane Zoomlion ZTC950V Second Hand Truck Mobile Crane wholesale

Brand Name : Zoomlion

Model Number : ZTC950V

Certification : CE, ISO9001

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, T/T

Delivery Time : 5-7 Days

Packaging Details : Bulk

Condition : Used

Maximum Lifting Height : 14 -87.5m

Maximum Lifting Weight : 95ton

Axle Number : 5

Jib : 6 Section

production date : 2018

Contact Now

Used Zoomlion Truck Crane Zoomlion ZTC950V Second Hand Truck Mobile Crane

Production Details:

Model No.	ZTC950V	Boom Type	Telescopic
Max. Rated Lifting Capacity	950000 kg	Max. Lifting Height of Jib	64m
Max Gradeability	40%	Working Diameter	23m
Transport Package	Complies with Min. export packaging requirements	Specification	15400×3000×3950MM
Driving Mileage	10000M	Working hours	1481h
Trademark	Zoomlion	Place of Origin	China
HS Code		Supply Capacity	10 Units/ Month

6-section 63-meter oval main boom, 3-section 24.5-meter jib,**Maximum lifting height is 87.5 meters;
Industry classic gold transmission chain, strong power, mature and reliable, good passability; reserved space for 10t bottom counterweight and two truss arms (17.5m) that can be attached to the vehicle to reduce the cost of use; standard reversing radar, main winch monitoring system And visual reversing image, safe and reliable.

This machine was manufactured in April 2018, worked 1667 hours, 95 tons of 6-section boom truck crane, Euro 5 emission, original format original paint of the whole vehicle, no repairs, one set of counterweight, two-section jibs, three hooks (70t , 25t, 7t), the product has excellent performance and is your best choice.

Product Parameters:

Item		Value	Remarks
Working performance	Max. rated lifting capacity (Kg)	95000	3m range
	Max. load moment of the basic boom (KN.m)	4000	5m range
	Max. load moment of long main boom (KN.m)	1860	30m range
	Basic boom max. lifting height (m)	14
	Main boom max. lifting height (m)	64	The boom deformation is not considered, and the value in brackets is the value of the standard jib
	Jib max. lifting height (m)	80.5/ (87.5)
Working speeds	Max. hoist rope spee (main winch) (m/min)	110	Reel fifth layer
	Max. hoist rope spee (auxiliary winch) (m/min)	75	Reel third layer
	Boom derricking up time (s)	70
	Boom telescoping out time (min)	13
	Max. slewing speed (r/min)	1.5
Traveling parameters	Max. use altitude (m)	2000
	High travel speed (Km/h)	75
	Max. gradeability (%)	40
	Min. turning diameter (m)	23
	Min. ground clearance (mm)	300
	Limits for exhaust pollutants and smoke	Conform to related standards	GB3847-2005 GB17691-2005 (Euro V)
	Oil consumption per 100 km (L)	70
Weights	Deadweight in traveling condition (Kg)	54900	In the driving state, the jib, 25t hook, 7t auxiliary hook, auxiliary winch mechanism (including auxiliary coil wire rope) and movable counterweight of the crane cannot be driven with the vehicle and need to be disassembled; with arm tip pulley, 70t crane.
	Complete vehicle kerb mass (Kg)	54705
	Ⅰ, Ⅱ axle load (Kg)	9950/9950
	IV, V, VI axle load (Kg)	25100 (Dual axis) /9900
